Magnesium Anodes

ISO 9001 Certified
ISO 17025 Accredited cert. #3612.01

Applications

Magnesium anodes are economical and effective corrosion fighters that have been in use for
well over 50 years and have been successfully protecting steel structures in fresh, brackish, and salt
water environments as well as high resistivity soils. Applications for Magnesium Anodes include:

• Hulls of ships, barges, tugs, and boats
• Ballast Tanks for ore carriers and similar vessels
• Water Storage Tanks
• Piers and Pilings
• Pipelines
• Heat Exchangers
• Traveling Screens
• Dams, Locks, and Gates

Marine Hull Anodes H-1 Alloy (AZ-63)

Marine Hull Anodes are available with or without Plastisol coating that serves as an excellent current
barrier.

L W H Weight
Product I.D.
in mm in mm in mm lbs kg
GA-MG-10-Launch 12 305 6 152.4 3 76.2 10 4.5
GA-MG-5-Launch 10 254 5 127 2 1/2 63.5 5 2.3
GA-MG-JR 9 228.6 3 76.2 1 3/8 34.9 1.5 0.7
GA-MG-H-22 10 254 20 508 2 51 22 10
GA-MG-H-12W 9 228.6 9 228.6 2 51 12 5.4
GA-MG-H-24W 18 457.2 9 228.6 2 51 24 10.9
GA-MG-44W 19 482.6 9 228.6 4 101.6 44 20
All Magnesium Anode weights and dimensions are nominal
